MoFi Electronics Tracker MM Phono Cartridge

MoFi cartridges are designed by looking at where a record starts: On a cutting lathe like the model used at Mobile Fidelity Sound Lab. MasterTracker features a V-Twin dual-magnet generator that mirrors the layout of the cutting head that originally makes a record’s grooves. Employing two low-mass, powerful magnets aligned in a V formation parallel with the record grooves, MasterTracker accurately extracts music from your LPs and features stellar tracking ability.

WELL-DAMPED BILLET ALUMINUM BODY
The well-damped billet aluminum body controls resonances for tight, accurate bass reproduction. MasterTracker has the lightest-weight magnets in the Tracker Series, delivering the kind of detailed, open performance normally attributed to high-end moving-coil cartridges.

MICRO-LINE DIAMOND STYLUS
By using a Micro-Line diamond stylus shaped like the cutting head of a record lathe, MasterTracker traces vinyl groove walls with microscopic precision.

Specifications:

• Type:  Dual Magnet (MM) Stereo
• Stylus:  Micro-Line
• Output Voltage:  3mV
• Frequency Response:  20 - 25,000Hz
• Weight:  9.7g
• Tracking Force:  1.8 - 2.2g
• Impedance:  47kOhm
• Capacitance:  100pF
• Compliance:  Static compliance : 40 x 10e-6/dyne,   Dynamic compliance : 10 x 10e-6/dyne
